DVA KS20

Bas refleks muhafazasında çift 18" woofer eşleştirmesine sahip DVA KS20, 4000 W Maksimum güç sağlayan iki Digipro G3 Güç Amplifikatörüyle donatılmıştır. Sistemin dahili tasarımı, bas refleks ve horn yüklü sistemlerin avantajlarını sağlam siyah lake kaplı kompakt, sağlam bir muhafazada bir araya getirir. 56 Bit DSP, kusursuz sistem işleme için sınırlayıcıları ve gecikmeleri yönetir.
DVA KS20, daha büyük DVA K5 sistemleri için mükemmel bir alt uç tamamlayıcıdır ve üstteki DRK-20/10 seçim noktaları sayesinde yere yığılmış konfigürasyonlarda dikey olarak kullanılabilir.

Technical Data
Speaker Type Active Bassreflex-Horn loaded Subwoofer
Acoustical data
Frequency Response [- 10 dB] 41 Hz - 120 Hz
Max SPL 138 dB
Directivity Omnidirectional
LF 2x18 "
Voice Coil LF 4 "
Amplifier
Amp Technology Digipro® G3
Amp Class Class D
RMS Power 1800 W
Peak Power 3600 W
Cooling Convection
Power Supply 1800 W SMPS with auto range PSU
Processor
Controller DSP 56 Bit
AD/DA Converter 24 Bit /48 Hz
System Presets X-Over, Delay
Limiter Dual Active Multiband RMS, Peak, Thermal
Crossover Frequency LF-HF 90, 120 Hz (selectable)
Slope LF-HF 24 dB/Octave
Input
Input Selection 2x XLR Balanced
Output Selection 2x XLR Balanced
Power Socket 1x PowerCON in + 1x PowerCON Out
Controls 1 x Input Sensitivity Rotary Switch
  1 x Setup Rotary Encoder (delay up to 4.5 ms on-board)
  1 x Polarity Inversion Switch
  1 x X-over Frequency Switch (90 Hz, 120 Hz)
  1 x Output mode Switch (Link- X-Over)
Mechanics
Housing Plywood
Handles 3x Per Side
Rigging Points 2xPick Points on top to fix
  DRK10/20 rigging frames
Pole Mount 1 xM20 on top
Width 1100 mm (43.31 in)
Height 580 mm (22.83 in)
Depth 720 mm (28.53 in)
Weight 84 kg (185.19 lbs)
