CRV/B

  • Marka : JBL
  • Ürün Kodu :

CRV'yi kontrol et
70V/100V Trafolu Yüksek Tasarımlı Hoparlör. Hava Direnci. Benzersiz, çağdaş, kavisli tasarım. Çift 100 mm (4 inç) woofer'lar üstün ses kalitesi sağlar. Yarım yuvarlak veya tam 360° yuvarlak yay kümeleri halinde birleştirilebilir.

Frequency Range 80 Hz - 20 kHz
Power Capacity 75 W continuous pink noise (300 W peak)
Transformer Selectable 70V/100V or low impedance
Usability Indoor/outdoor capable
Colors Black, or White (-WH)
Sensitivity 89 dB, 1W@1m
Maximum SPL (1m) 108 dB continuous average long-term (peaks of 114 dB)
Coverage Angle 105°H x80°V
Impedance 4 Ohms
Transformer Taps 30 W, 15 W, 7.5 W (plus 3.8 W @ 70 V only), plus Thru
Drivers LF Driver: Dual 4" (100 mm)
HF Driver: 3/4" (19 mm)
Input Connectors Screw-down terminal strip
Grille Zinc-plated steel
Mounting Hardware Included wall-mount bracket. Optional pole-mount accessory.
Outdoor Capability IP-34 rating. Exceeds MilSpec 810 for humidity, salt spray, temperature & UV. Passes Mil-Std-202F for salt spray
Included Accessories Corner/wall-mount bracket with cap, screws, and trim covers
Optional Accessories Pole-Mount Bracket for 4-speaker 360° hanging pendant cluster
