VTX F35/95

  • Marka : JBL
  • Ürün Kodu :

Özellikler
Hafif trapezoidal muhafaza içinde D2 Çift Diyaframlı Çift Ses Bobini yüksek frekanslı sıkıştırma sürücüsünü içeren yüksek çıkışlı 3 yollu muhafaza

Diferansiyel Sürücü, Çift Neodimyum Mıknatıs, Çift Ses Bobini, Doğrudan Soğutmalı MF ve LF koni dönüştürücüler

Çoklu M10 bağlantı noktaları çeşitli askı seçeneklerini kolaylaştırır

Crown Audio I-Tech HD serisi amplifikatörlerle kullanım için V5 İşleme

Frequency Range (-10dB) 39 Hz - 18 kHz
Coverage Pattern (-6dB) /64: 60° Horizontal x 40°Vertical/95: 90° Horizontal x 50°Vertical
System Input Power Rating LF: 2 x 800 W Continuous (IEC / 100 hour)MF: 270 W Continuous (IEC / 100 hour)HF: 100 W Continuous (IEC / 100 hour)
Maximum Peak Output *2 /64: 143dB (Preset: F35/64 FR)/95: 143dB (Preset: -F35/95 FR)
System Processing Crown Audio I-Tech HD SeriesCrown Audio I-Tech 4x3500HD
System Impedance LF = 2 x 8 ohms
MF = 8 ohms
HF = 8 ohms
LF Driver 2 x 2265H, 254 mm (15 in) diameter, dual 76 mm (3 in) diameter voice coil, NDD®, Direct Cooled
MF Driver 1 x 2169H, 203 mm (8 in) dia., 76mm (3 in) Dual Voice Coil, Neodymium Differential Drive®, Direct Cooled
HF Driver 1 x D2430H, D2 dual diaphragm, dual 76mm (3 in) diameter voice coil
Enclosure 18 mm, 11-ply Finnish birch plywood; black DuraFlex finish; integral recessed handles
Grille Powder Coated 14 gauge hex-perforated steel with acoustically-transparent black cloth backing
Input Connectors Neutrik® Speakon® NL-8 (2x): LF1: 1± | LF2: 2± | MF: 3± | HF: 4±
Dimensions (H x W x D) 1051.5mm x 568.9mm x 528.3mm (41.4in x 22.4in x 20.8in)
Net Weight (each) 52.6 kg (116 lbs)
System Type High Performance Dual 15" 3-Way Loudspeaker with 90 x 50 degree coverage
Suspension / Mounting Integrated M10 mounting points
