PLX-1000

PLX-1000
Profesyonel doğrudan tahrikli pikap

Yeniden doğmuş bir klasik

PLX-1000, üst düzey pikap yapımında 50 yıllık deneyimden yararlanılarak stant için hassas bir şekilde tasarlanmıştır. Sonuç olarak, yüksek torklu doğrudan tahrik sistemi, çok aralıklı kontrol, kulüp düzeyinde yapı ve ses kalitesi ve ayrılabilir... Devamını oku

Main Features
Accessories PLX-1000, Power cord, Audio cable, Ground wire, Adapter for EP record, Turntable sheet, Slip mat and sheet, Dust cover, Head shell, Balance, sub and shell weights, Operating instructions
Specifications
Width 453 mm
Depth 353 mm
Height 159 mm
Weight 14.6 kg
Turntable
Drive Method Quartz lock, servo-type, direct drive
Turntable Aluminium, die-casting diameter: 332 mm
Motor 3-phase, brushless DC motor
Braking System Electronic brake
Rotation Speed 33? rpm, 45 rpm
Rotation Adjustment Range ±8, ±16, ±50 %
Wow and Flutter 0.1 % or less WRMS (JIS WTD)
Signal-to-Noise Ratio 70 dB
Starting Torque > 4.5 kgf?cm
Start Time 0.3 sec (at 33? rpm)
Tone Arm
Arm Type Universal type S-shape tone arm, Gimbal-supported type bearing structure, Static balance type
Overhang 15 mm
Effective Length 230 mm
Tracking Error Within 3°
Height Adjustment Range 6 mm
Stylus Pressure Variable Range 0-4 g (1 scale 0.1 g)
Proper Cartridge Weight 2.5-12 g (includes mounting materials)
Terminals
Outputs 1 ANALOGUE (RCA)
