VF 2224 TWIN FLAT

  • Marka : IVOX
  • Ürün Kodu :

VF 2224 kablo, Broadcast sistemi ve düz kabloların gerekli olduğu mobil kurulumlarda kullanılmak üzere tasarlanmıştır. Bu kablo, iki kanallı XLR bağlantısı profesyonel sahne ve stüdyo işlemlerini bağlamak için özellikle uygundur.

Core Numbers x Section 2 x 2 x 0,22 mm² (AWG 24)
Stranded Copper Conductor 28 x 0,10 mm ø Stranded Bare Copper
Conductor Insulation 1,50 ± 0,05 mm ø XLPE
Conductor Color Code Blue / Red
Shielding 1 st Copper spiral shielding
Shielding 2 nd Copper spiral shielding
Shielding Factor 100%
Outer Sheath sPVC
Outer Diameter 3,5 x 7,4 mm ø
Weight 4.1 kg/100 m
Conductor Resistance < 86 Ohm / km
Shield Resistance < 22 Ohm / km
Insulation Resistance > 2000 MOhm x km
Capacitance core/core 80 pF / m
Capacitance core/screen 135 pF / m
Minimum bending radius 10x D ( D= outer diameter )
Temperature range Mobile installation - 5° C to + 70° C
Temperature range Fixed installation -30° C to + 70° C
