NL8MMXX

Kablo uzantıları için 8 kutuplu talkON geçiş bağlayıcısı

Product
Title	NL8MMXX
Connection Type	Adapter
Gender	male
Electrical
Contact resistance	< 3 mOhm
Dielectric strength	1.5 kVac
Insulation resistance	> 0.1 GOhm (after dampheat)
Rated current per contact	25 A rms continuous
Rated voltage	250 V ac
Attention	speakON is NOT to be used as an mains or power supply connector (AC / DC)!
Mechanical
Lifetime	> 5000 mating cycles
Locking device	Quick Lock
Material
Contact plating	Ag
Contacts	Copper Alloy
Shell	Zinc diecast, black chrome plated
Insert	Polyamide (PA 6.6)
Environmental
Temperature range	-30 °C to +80 °C
Flammability	UL 94 V-0
