NC3FM-C-B

Dünyanın ilk 3 kutuplu unisex XLR kablo konnektörü, siyah

Özellikler ve Faydalar

Dünyanın ilk uniseks XLR'ı
Tek muhafazada 3 kutuplu erkek ve dişi kablo konnektörü
Kolay seçilebilen cinsiyet - muhafazanın ileri geri kaydırılmasıyla dönüştürülür
Acil durum kiti olarak ideal yedek adaptörler
XLR XX serisinin tüm avantajlarıyla birlikte

Product
Title	NC3FM-C-B
Connection Type	XLR
Gender	female
Electrical
Capacitance between contacts	<= 4 pF
Contact resistance	<= 3 mOhm
Dielectric strength	1.5 kVdc
Insulation resistance	> 2 GOhm (initial)
Rated current per contact	16 A
Rated voltage	<50 V
Mechanical
Cable O.D.	3.5 - 8.0 mm
Insertion force	<= 20 N
Withdrawal force	<= 20 N
Lifetime	> 1000 mating cycles
Wiresize	max. 2.5 mm²
Wiresize	max. 14 AWG
Wiring	Solder contacts
Locking device	Latch lock
Material
Boot	Polyurethan
Contact plating	0.2 µm Au
Contacts	Brass (CuZn39Pb3) (male)
Insert	Polyamdie (PA 6.6 30 % GR)
Locking element	Zinc diecast (ZnAl4Cu1) / Ck 67 (spring)
Shell	Black chromium
Shell plating	Nickel
Strain relief	Polyacetal (POM)
Environmental
Flammability	UL 94 HB
Standard compliance	IEC 61076-2-103
Protection class	IP 40
Solderability	Complies with IEC 68-2-20
Temperature range	-30 °C to +80 °C
